Drill bits М40
Brief specifications
- Image
- Name KNSH-110 M40 MH 546.00
- Nominal drill bit diameter, mm 110
- Gauge angle, deg. 35
- Carbide (outer) Hemispherical 8 × Ø14
- Carbide (front) Hemispherical 6 × Ø14
- Flushing holes 2
- Length L, mm 311
- Weight, kg 8.6
KNSH-110 M40 MH 546.00
PART NUMBER: MH 546.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-110 M40 MH 566.00
- Nominal drill bit diameter, mm 110
- Gauge angle, deg. 35
- Carbide (outer) Hemispherical 8 × Ø16
- Carbide (front) Hemispherical 6 × Ø16
- Flushing holes 2
- Length L, mm 321
- Weight, kg 8.6
KNSH-110 M40 MH 566.00
PART NUMBER: MH 566.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Name KNSH-115 M40 MH 579.00
- Nominal drill bit diameter, mm 115
- Gauge angle, deg. 35
- Carbide (outer) Hemispherical 8 × Ø16
- Carbide (front) Hemispherical 6 × Ø14
- Flushing holes 2
- Length L, mm 321
- Weight, kg 9.3
KNSH-115 M40 MH 579.00
PART NUMBER: MH 579.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-127 M40 MH 587.00
- Nominal drill bit diameter, mm 127
- Gauge angle, deg. 35
- Carbide (outer) Hemispherical 8 × Ø14
- Carbide (front) Hemispherical 8 × Ø14
- Flushing holes 2
- Length L, mm 321
- Weight, kg 10.2
KNSH-127 M40 MH 587.00
PART NUMBER: MH 587.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-130 M40 MH 514.00
- Nominal drill bit diameter, mm 130
- Gauge angle, deg. 35
- Carbide (outer) Hemispherical 8 × Ø16
- Carbide (front) Hemispherical 8 × Ø14
- Flushing holes 2
- Length L, mm 320.5
- Weight, kg 10.2
KNSH-130 M40 MH 514.00
PART NUMBER: MH 514.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-130 M40 MH 516.00
- Nominal drill bit diameter, mm 130
- Gauge angle, deg. 40 20
- Carbide (outer) Semi-ballistic 9 × Ø16
- Carbide (front) Semi-ballistic 6 × Ø16
- Flushing holes 3
- Length L, mm 321.5
- Weight, kg 9.82
KNSH-130 M40 MH 516.00
PART NUMBER: MH 516.00
Check with the manager for the information about availability and delivery terms after submitting your application
