Drill bits QL80
Brief specifications
- Image
- Name KNSH-203 QL80 MH 575.00
- Nominal drill bit diameter, mm 203
- Gauge angle, deg. 35
- Carbide (outer) Hemispherical 10 × Ø19
- Carbide (front) Hemispherical 17 × Ø16
- Flushing holes 3
- Length L, mm 454
- Weight, kg 49.2
KNSH-203 QL80 MH 575.00
PART NUMBER: MH 575.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-203 QL80 MH 576.00
- Nominal drill bit diameter, mm 203
- Gauge angle, deg. 35
- Carbide (outer) Hemispherical 10 × Ø18
- Carbide (front) Hemispherical 12 × Ø16
- Flushing holes 3
- Length L, mm 454
- Weight, kg 50.8
KNSH-203 QL80 MH 576.00
PART NUMBER: MH 576.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-216 QL80 MH 889.00
- Nominal drill bit diameter, mm 216
- Gauge angle, deg. 35 15
- Carbide (outer) Hemispherical 27 × Ø19
- Carbide (front) Hemispherical 6 × Ø19
- Flushing holes 3
- Length L, mm 455
- Weight, kg 52
KNSH-216 QL80 MH 889.00
PART NUMBER: MH 889.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-216 QL80 MH 890.00
- Nominal drill bit diameter, mm 216
- Gauge angle, deg. 40 20
- Carbide (outer) Hemispherical 27 × Ø19
- Carbide (front) Hemispherical 7 × Ø19
- Flushing holes 3
- Length L, mm 455
- Weight, kg 52
KNSH-216 QL80 MH 890.00
PART NUMBER: MH 890.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-222 QL80 MH 577.00
- Nominal drill bit diameter, mm 222
- Gauge angle, deg. 35
- Carbide (outer) Hemispherical 12 × Ø19
- Carbide (front) Hemispherical 14 × Ø19
- Flushing holes 3
- Length L, mm 455
- Weight, kg 54.1
KNSH-222 QL80 MH 577.00
PART NUMBER: MH 577.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-222 QL80 MH 594.00 (gauge reinforcement)
- Nominal drill bit diameter, mm 222
- Gauge angle, deg. 35
- Carbide (outer) Hemispherical 21 × Ø18
- Carbide (front) Hemispherical 10 × Ø16
- Flushing holes 3
- Length L, mm 450
- Weight, kg 52.6
KNSH-222 QL80 MH 594.00 (gauge reinforcement)
PART NUMBER: MH 594.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-251 QL80 MH 586.00 (gauge reinforcement)
- Nominal drill bit diameter, mm 251
- Gauge angle, deg. 35
- Carbide (outer) Hemispherical 10 × Ø19
- Carbide (front) Hemispherical 10 × Ø16
- Flushing holes 2
- Length L, mm 455
- Weight, kg 61.2
KNSH-251 QL80 MH 586.00 (gauge reinforcement)
PART NUMBER: MH 586.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-254 QL80 MH 588.00
- Nominal drill bit diameter, mm 254
- Gauge angle, deg. 35
- Carbide (outer) Hemispherical 10 × Ø19
- Carbide (front) Hemispherical 18 × Ø19
- Flushing holes 2
- Length L, mm 455
- Weight, kg 61.5
KNSH-254 QL80 MH 588.00
PART NUMBER: MH 588.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH-254 QL80 MH 583.00 (gauge reinforcement)
- Nominal drill bit diameter, mm 254
- Gauge angle, deg. 35
- Carbide (outer) Hemispherical 10 × Ø19
- Carbide (front) Hemispherical 18 × Ø19, 10 × Ø16
- Flushing holes 2
- Length L, mm 455
- Weight, kg 61.9
KNSH-254 QL80 MH 583.00 (gauge reinforcement)
PART NUMBER: MH 583.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name Valve MH 577.02
Valve MH 577.02
PART NUMBER: MH 577.02
Check with the manager for the information about availability and delivery terms after submitting your application
