Drill bits for hydraulic rock drills R25 thread
Brief specifications
- Image
- Nominal drill bit diameter, mm33
- Gauge angle, deg.40
- Carbide (outer)semi-ballistic 5 × Ø7
- Carbide (front)semi-ballistic 2 × Ø7
- Flushing holes3
- Length, mm99
- Weight, kg0.34
KNSH 33-R25.FSp MH 704.00
PART NUMBER: MH 704.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Nominal drill bit diameter, mm35
- Gauge angle, deg.30
- Carbide (outer)semi-ballistic 5 × Ø9
- Carbide (front)semi-ballistic 2 × Ø7
- Flushing holes3
- Length, mm99.4
- Weight, kg0.4
KNSH 35-R25.FSp MH 705.00
PART NUMBER: MH 705.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Nominal drill bit diameter, mm35
- Gauge angle, deg.30
- Carbide (outer)Hemispherical 5 × Ø9
- Carbide (front)Hemispherical 2 × Ø7
- Flushing holes3
- Length, mm99
- Weight, kg0.4
KNSH 35-R25.FS MH 736.00
PART NUMBER: MH 736.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Nominal drill bit diameter, mm35
- Gauge angle, deg.40
- Carbide (outer)semi-ballistic 5 × Ø8
- Carbide (front)semi-ballistic 2 × Ø7
- Flushing holes2
- Length, mm96
- Weight, kg0.37
KNSH 35-R25.ВSp MH 703.00
PART NUMBER: MH 703.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Nominal drill bit diameter, mm38
- Gauge angle, deg.35
- Carbide (outer)semi-ballistic 5 × Ø9
- Carbide (front)semi-ballistic 2 × Ø8
- Flushing holes2
- Length, mm101
- Weight, kg0.52
KNSH 38-R25.ВSp MH 706.00
PART NUMBER: MH 706.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Nominal drill bit diameter, mm38
- Gauge angle, deg.40
- Carbide (outer)conical 5 × Ø9
- Carbide (front)conical 2 × Ø7
- Flushing holes2
- Length, mm100
- Weight, kg0.52
KNSH 38-R25.ВSk MH 707.00
PART NUMBER: MH 707.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Nominal drill bit diameter, mm41
- Gauge angle, deg.40
- Carbide (outer)semi-ballistic 5 × Ø9
- Carbide (front)semi-ballistic 2 × Ø8
- Flushing holes2
- Length L, mm100.5
- Weight, kg0.55
KNSH 41-R25.BSp MH 1126.00
PART NUMBER: MH 1126.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Nominal drill bit diameter, mm45
- Gauge angle, deg.40
- Carbide (outer)semi-ballistic 6 × Ø9
- Carbide (front)semi-ballistic 3 × Ø8
- Flushing holes3
- Length, mm95
- Weight, kg0.69
KNSH 45-R25.BSp MH 1120.00
PART NUMBER: MH 1120.00
Check with the manager for the information about availability and delivery terms after submitting your application
