Drill bits for hydraulic rock drills T38 thread
Brief specifications
- Image
- NameKNSH 64-Т38.ВS MH 353.00
- Nominal drill bit diameter, mm64
- Gauge angle, deg.30
- Carbide (outer)Hemispherical 8 × Ø10
- Carbide (front)Hemispherical 4 × Ø10
- Flushing holes2
- Length, mm132.5
- Weight, kg1.8
KNSH 64-Т38.ВS MH 353.00
PART NUMBER: MH 353.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- NameKNSH 64-Т38.S MH 685.00
- Nominal drill bit diameter, mm64
- Gauge angle, deg.30
- Carbide (outer)Hemispherical 6 × Ø12
- Carbide (front)Hemispherical 3 × Ø11
- Flushing holes3
- Length, mm126
- Weight, kg1.7
KNSH 64-Т38.S MH 685.00
PART NUMBER: MH 685.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- NameKNSH 64-Т38.Sp MH 679.00
- Nominal drill bit diameter, mm64
- Gauge angle, deg.35
- Carbide (outer)semi-ballistic 6 × Ø12
- Carbide (front)semi-ballistic 3 × Ø11
- Flushing holes3
- Length, mm126.5
- Weight, kg1.7
KNSH 64-Т38.Sp MH 679.00
PART NUMBER: MH 679.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- NameKNSH 64-Т38.RSp MH 642.00
- Nominal drill bit diameter, mm64
- Gauge angle, deg.35
- Carbide (outer)semi-ballistic 6 × Ø12
- Carbide (front)semi-ballistic 3 × Ø11
- Flushing holes3
- Length, mm146.5
- Weight, kg1.9
KNSH 64-Т38.RSp MH 642.00
PART NUMBER: MH 642.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- NameKNSH 64-Т38.ARSp MH 661.00
- Nominal drill bit diameter, mm64
- Gauge angle, deg.35
- Carbide (outer)semi-ballistic 8 × Ø10
- Carbide (front)semi-ballistic 5 × Ø9
- Flushing holes4
- Length, mm145.5
- Weight, kg1.9
KNSH 64-Т38.ARSp MH 661.00
PART NUMBER: MH 661.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- NameKNSH 76-Т38.ARS MH 639.00
- Nominal drill bit diameter, mm76
- Gauge angle, deg.35
- Carbide (outer)Hemispherical 8 × Ø11
- Carbide (front)Hemispherical 5 × Ø11
- Flushing holes4
- Length, mm148.5
- Weight, kg3.1
KNSH 76-Т38.ARS MH 639.00
PART NUMBER: MH 639.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- NameKNSH 89-Т38.ARS MH 636.00
- Nominal drill bit diameter, mm89
- Gauge angle, deg.35
- Carbide (outer)Hemispherical 8 × Ø12
- Carbide (front)Hemispherical 6 × Ø12
- Flushing holes4
- Length, mm161.5
- Weight, kg5.1
KNSH 89-Т38.ARS MH 636.00
PART NUMBER: MH 636.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- NameKNSH 64-Т38.ARS MH 338.00
- Nominal drill bit diameter, mm64
- Gauge angle, deg.35
- Carbide (outer)Hemispherical 6 × Ø10
- Carbide (front)Hemispherical 4 × Ø10
- Flushing holes3
- Length, mm145.5
- Weight, kg1.9
KNSH 64-Т38.ARS MH 338.00
PART NUMBER: MH 338.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- NameKNSH 76-Т38.ARSp MH 340.00
- Nominal drill bit diameter, mm76
- Gauge angle, deg.35
- Carbide (outer)semi-ballistic 9 × Ø11
- Carbide (front)semi-ballistic 9 × Ø9
- Flushing holes3
- Length, mm147.5
- Weight, kg3.3
KNSH 76-Т38.ARSp MH 340.00
PART NUMBER: MH 340.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- NameKNSH 89-Т38.ARSp MH 292.00
- Nominal drill bit diameter, mm89
- Gauge angle, deg.35
- Carbide (outer)semi-ballistic 9 × Ø12
- Carbide (front)semi-ballistic 9 × Ø11
- Flushing holes3
- Length, mm161.5
- Weight, kg5.4
KNSH 89-Т38.ARSp MH 292.00
PART NUMBER: MH 292.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- NameKNSH 76-Т38.ВS MH 356.00
- Nominal drill bit diameter, mm76
- Gauge angle, deg.35
- Carbide (outer)Hemispherical 9 × Ø10
- Carbide (front)Hemispherical 5 × Ø10
- Flushing holes3
- Length, mm147.8
- Weight, kg2.8
KNSH 76-Т38.ВS MH 356.00
PART NUMBER: MH 356.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- NameKNSH 76-Т38.Sp MH 368.00
- Nominal drill bit diameter, mm76
- Gauge angle, deg.35
- Carbide (outer)semi-ballistic 8 × Ø12
- Carbide (front)semi-ballistic 5 × Ø11
- Flushing holes4
- Length, mm149
- Weight, kg2.8
KNSH 76-Т38.Sp MH 368.00
PART NUMBER: MH 368.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- NameKNSH 64-Т38.RSp MH 359.00
- Nominal drill bit diameter, mm64
- Gauge angle, deg.35
- Carbide (outer)semi-ballistic 8 × Ø10
- Carbide (front)semi-ballistic 5 × Ø9
- Flushing holes4
- Length, mm145.5
- Weight, kg1.9
KNSH 64-Т38.RSp MH 359.00
PART NUMBER: MH 359.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- NameKNSH 76-Т38.RSp MH 650.00
- Nominal drill bit diameter, mm76
- Gauge angle, deg.35
- Carbide (outer)semi-ballistic 8 × Ø12
- Carbide (front)semi-ballistic 5 × Ø11
- Flushing holes4
- Length, mm149
- Weight, kg3.1
KNSH 76-Т38.RSp MH 650.00
PART NUMBER: MH 650.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- NameKNSH 89-Т38.AS MH 349.00
- Nominal drill bit diameter, mm89
- Gauge angle, deg.35
- Carbide (outer)Hemispherical 8 × Ø13
- Carbide (front)Hemispherical 5 × Ø11
- Flushing holes4
- Length, mm148.5
- Weight, kg3.2
KNSH 89-Т38.AS MH 349.00
PART NUMBER: MH 349.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- NameKNSH 102-T38.ASp MH 698.00
- Nominal drill bit diameter, mm102
- Gauge angle, deg.35
- Carbide (outer)semi-ballistic 9 × Ø13
- Carbide (front)semi-ballistic 9 × Ø12
- Flushing holes3
- Length, mm149.5
- Weight, kg5.3
KNSH 102-T38.ASp MH 698.00
PART NUMBER: MH 698.00
Check with the manager for the information about availability and delivery terms after submitting your application
