Drill bits for hydraulic rock drills T51 thread
Brief specifications
- Image
- Name KNSH 89-T51.BSp MH 680.00
- Nominal drill bit diameter, mm 89
- Gauge angle, deg. 35
- Carbide (outer) semi-ballistic 10 × Ø12
- Carbide (front) semi-ballistic 8 × Ø11
- Flushing holes 3
- Length, mm 161.5
- Weight, kg 4.1
KNSH 89-T51.BSp MH 680.00
PART NUMBER: MH 680.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH 89-T51.BSp MH 681.00
- Nominal drill bit diameter, mm 89
- Gauge angle, deg. 30
- Carbide (outer) semi-ballistic 9 × Ø12
- Carbide (front) semi-ballistic 6 × Ø11, 3 × Ø11
- Flushing holes 3
- Length, mm 161.5
- Weight, kg 4.1
KNSH 89-T51.BSp MH 681.00
PART NUMBER: MH 681.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH 89-T51.ARSp MH 276.00
- Nominal drill bit diameter, mm 89
- Gauge angle, deg. 35
- Carbide (outer) semi-ballistic 9 × Ø12
- Carbide (front) semi-ballistic 9 × Ø11
- Flushing holes 3
- Length, mm 176.5
- Weight, kg 5.1
KNSH 89-T51.ARSp MH 276.00
PART NUMBER: KNSH 89-T51.ARSp MH 276.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH 89-T51.ASp MH 655.00
- Nominal drill bit diameter, mm 89
- Gauge angle, deg. 35
- Carbide (outer) semi-ballistic 8 × Ø12
- Carbide (front) semi-ballistic 6 × Ø12
- Flushing holes 6
- Length, mm 162
- Weight, kg 4
KNSH 89-T51.ASp MH 655.00
PART NUMBER: MH 655.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH 89-T51.Sp MH 630.00
- Nominal drill bit diameter, mm 89
- Gauge angle, deg. 40
- Carbide (outer) semi-ballistic 8 × Ø13
- Carbide (front) semi-ballistic 5 × Ø12
- Flushing holes 4
- Length, mm 162
- Weight, kg 4
KNSH 89-T51.Sp MH 630.00
PART NUMBER: MH 630.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH 89-T51.Sb MH 635.00
- Nominal drill bit diameter, mm 89
- Gauge angle, deg. 35
- Carbide (outer) ballistic 8 × Ø13
- Carbide (front) ballistic 5 × Ø13
- Flushing holes 4
- Length, mm 163
- Weight, kg 4.2
KNSH 89-T51.Sb MH 635.00
PART NUMBER: MH 635.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH 89-Т51.ASk MH 1112.00
- Nominal drill bit diameter, mm 89
- Gauge angle, deg. 35
- Carbide (outer) conical 8 × Ø13
- Carbide (front) conical 5 × Ø13
- Flushing holes 6
- Length, mm167.5
- Weight, kg 4.2
KNSH 89-Т51.ASk MH 1112.00
PART NUMBER: MH 1112.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH 89-T51.RSp MH 629.00
- Nominal drill bit diameter, mm 89
- Gauge angle, deg. 40
- Carbide (outer) semi-ballistic 8 × Ø13
- Carbide (front) semi-ballistic 5 × Ø12
- Flushing holes 4
- Length, mm 177
- Weight, kg 4.5
KNSH 89-T51.RSp MH 629.00
PART NUMBER: MH 629.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH 89-T51.RSp MH 629.00
- Nominal drill bit diameter, mm 89
- Gauge angle, deg. 40
- Carbide (outer) semi-ballistic 8 × Ø13
- Carbide (front) semi-ballistic 5 × Ø12
- Flushing holes 4
- Length, mm 177
- Weight, kg 4.5
KNSH 89-T51.RSp MH 629.00
PART NUMBER: MH 629.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH 89-T51.BS MH 364.00
- Nominal drill bit diameter, mm 89
- Gauge angle, deg. 35
- Carbide (outer) Hemispherical 8 × Ø14
- Carbide (front) Hemispherical 4 × Ø14
- Flushing holes 2
- Length, mm 172.5
- Weight, kg 4.2
KNSH 89-T51.BS MH 364.00
PART NUMBER: MH 364.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH 89-T51.BRS MH 348.00
- Nominal drill bit diameter, mm 89
- Gauge angle, deg. 35
- Carbide (outer) Hemispherical 8 × Ø12
- Carbide (front) Hemispherical 6 × Ø12
- Flushing holes 2
- Length, mm 176.5
- Weight, kg 4.7
KNSH 89-T51.BRS MH 348.00
PART NUMBER: MH 348.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH 89-T51.BRS MH 351.00
- Nominal drill bit diameter, mm 89
- Gauge angle, deg. 35
- Carbide (outer) Hemispherical 8 × Ø13
- Carbide (front) Hemispherical 6 × Ø13
- Flushing holes 2
- Length, mm 177
- Weight, kg 4.8
KNSH 89-T51.BRS MH 351.00
PART NUMBER: MH 351.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH 102-T51.BRS MH 20.00
- Nominal drill bit diameter, mm 102
- Gauge angle, deg. 35
- Carbide (outer) Hemispherical 9 × Ø12
- Carbide (front) Hemispherical 6 × Ø12
- Flushing holes 3
- Length, mm 166.5
- Weight, kg 5.4
KNSH 102-T51.BRS MH 20.00
PART NUMBER: MH 20.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH 102-T51.BRSp MH 42.00
- Nominal drill bit diameter, mm 102
- Gauge angle, deg. 35
- Carbide (outer) semi-ballistic 9 × Ø12
- Carbide (front) semi-ballistic 6 × Ø12
- Flushing holes 3
- Length, mm 167
- Weight, kg 5.5
KNSH 102-T51.BRSp MH 42.00
PART NUMBER: MH 42.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH 102-T51.RS MH 296.00
- Nominal drill bit diameter, mm 102
- Gauge angle, deg. 35
- Carbide (outer) Hemispherical 9 × Ø13
- Carbide (front) Hemispherical 9 × Ø11
- Flushing holes 3
- Length, mm 171
- Weight, kg 6.4
KNSH 102-T51.RS MH 296.00
PART NUMBER: MH 296.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH 102-T51.RSp MH 298.00
- Nominal drill bit diameter, mm 102
- Gauge angle, deg. 40
- Carbide (outer) semi-ballistic 9 × Ø13
- Carbide (front) semi-ballistic 9 × Ø11
- Flushing holes 3
- Length, mm 171.5
- Weight, kg 6.4
KNSH 102-T51.RSp MH 298.00
PART NUMBER: MH 298.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH 115-T51.RSp MH 286.00
- Nominal drill bit diameter, mm 115
- Gauge angle, deg. 40
- Carbide (outer) semi-ballistic 9 × Ø14
- Carbide (front) semi-ballistic 10 × Ø12
- Flushing holes 3
- Length, mm 182
- Weight, kg 9
KNSH 115-T51.RSp MH 286.00
PART NUMBER: MH 286.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH 102-T51.BRSp MH 299.00
- Nominal drill bit diameter, mm 102
- Gauge angle, deg. 40
- Carbide (outer) semi-ballistic 9 × Ø13
- Carbide (front) semi-ballistic 10 × Ø12
- Flushing holes 2
- Length, mm 172
- Weight, kg 6
KNSH 102-T51.BRSp MH 299.00
PART NUMBER: MH 299.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH 102-T51.BRSp MH 654.00
- Nominal drill bit diameter, mm 102
- Gauge angle, deg. 35
- Carbide (outer) semi-ballistic 9 × Ø16
- Carbide (front) semi-ballistic 6 × Ø14
- Flushing holes 2
- Length, mm 184
- Weight, kg 7.1
KNSH 102-T51.BRSp MH 654.00
PART NUMBER: MH 654.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH 115-T51.BRS MH 39.00
- Nominal drill bit diameter, mm 115
- Gauge angle, deg. 35
- Carbide (outer) Hemispherical 9 × Ø14
- Carbide (front) Hemispherical 9 × Ø12
- Flushing holes 3
- Length, mm 166.5
- Weight, kg 8.1
KNSH 115-T51.BRS MH 39.00
PART NUMBER: MH 39.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH 115-T51.BRSp MH 285.00
- Nominal drill bit diameter, mm 115
- Gauge angle, deg. 35
- Carbide (outer) semi-ballistic 9 × Ø14
- Carbide (front) semi-ballistic 9 × Ø12
- Flushing holes 3
- Length, mm 166.5
- Weight, kg 8.2
KNSH 115-T51.BRSp MH 285.00
PART NUMBER: MH 285.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH 115-T51.ARS MH 280.00
- Nominal drill bit diameter, mm 115
- Gauge angle, deg. 35
- Carbide (outer) Hemispherical 9 × Ø14
- Carbide (front) Hemispherical 7 × Ø14
- Flushing holes 3
- Length, mm 193
- Weight, kg 10
KNSH 115-T51.ARS MH 280.00
PART NUMBER: MH 280.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH 115-T51.ARSp MH 662.00
- Nominal drill bit diameter, mm 115
- Gauge angle, deg. 40
- Carbide (outer) semi-ballistic 8 × Ø16
- Carbide (front) semi-ballistic 6 × Ø14
- Flushing holes 4
- Length, mm 173.5
- Weight, kg 8.4
KNSH 115-T51.ARSp MH 662.00
PART NUMBER: MH 662.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH 115-T51.ARS MH 29.00
- Nominal drill bit diameter, mm 115
- Gauge angle, deg. 35
- Carbide (outer) Hemispherical 8 × Ø14
- Carbide (front) Hemispherical 7 × Ø13
- Flushing holes 4
- Length, mm 167
- Weight, kg 8.2
KNSH 115-T51.ARS MH 29.00
PART NUMBER: MH 29.00
Check with the manager for the information about availability and delivery terms after submitting your application
- Image
- Name KNSH 127-T51.ARS MH 23.00
- Nominal drill bit diameter, mm 127
- Gauge angle, deg. 35
- Carbide (outer) Hemispherical 8 × Ø14
- Carbide (front) Hemispherical 8 × Ø14
- Flushing holes 4
- Length, mm 167.5
- Weight, kg 10.5
KNSH 127-T51.ARS MH 23.00
PART NUMBER: MH 23.00
Check with the manager for the information about availability and delivery terms after submitting your application
Description
